Pellet Heating Systems

Power supply

400 V / 3 ph / 50 Hz

Heating capacity (min/nom/max) A7/W35

5.5 / 13 / 16 kW

Heating capacity (nom/max) A-7/W35

13 / 14 kW

Heating capacity (nom/max) A-7/W55

13 / 13 kW

COP (A7/W35)

4.5

SCOP 35°C 1~/3~

4.45 / 4.15

SCOP 55°C 1~/3~

3.41 / 3.28

Seasonal space heating efficiency 35°C 1~/3~

175 / 163

Seasonal space heating efficiency 55°C 1~/3~

133 / 128

Energy class 35°C 1~/3~

Α++

Energy class 55°C 1~/3~

Α++

Water outlet temperature range

20 / 60 °C

Max water temp. in thermodynamic mode (ambient -10°C)

60°C

Cooling capacity (nom/max) A35/W7

13 / 14.7 kW

EER (A35/W7) 1~/3~

3.22

Cooling capacity (nom/max) A35/W18

14 / 17 kW

EER (A35/W18) 1~/3~

4.65

Expansion tank

6 L

Water flow rate (min/nom/max)

1.2 / 2.24 / 3

Hydraulic connections

1’’1/4

Minimum system water volume

55 L

Maximum current

28.8 Α

Sound pressure at 1m / fan sound power (heating mode)

63 dB(A)

Airflow

8280 m3/h

Refrigerant

R32

Net weight

138 kg

Dimensions (HxWxD)

138 x 125.2 x 37 cm

Compressor type

Double-Rotary
